Motocross · Two stroke
Sold in Australia from 1990 to 2002, 13 model years. Below: the service intervals the MWMX Digital Garage runs on a CR80R, the parts assigned to fit it, and the used ones for sale on the Marketplace right now.
Engine hours between jobs, the schedule the Digital Garage tracks for you. Ride hard, in sand or mud, and halve the engine ones.
| Job | Every |
|---|---|
| Air filter clean and re-oil | 3h |
| Chain clean, lube and adjust | 3h |
| Spoke tension check | 8h |
| Fastener torque check | 8h |
| Transmission oil change | 10h |
| Cables and throttle lube | 15h |
| Air boot and intake seal check | 20h |
| Rings only replace | 20h |
| Spark plug replace | 20h |
| Power valve clean | 25h |
| Silencer repack | 25h |
| Rear brake pads | 25h |
| Linkage bearings grease | 30h |
| Tyres inspect / replace | 30h |
| Tubes and rim locks | 30h |
| Top end rebuild (piston and rings) | 40h |
| Clutch plates inspect | 40h |
| Chain slider, guide and roller | 40h |
| Fork service (oil and seals) | 40h |
| Front brake pads | 40h |
| Grips inspect / replace | 40h |
| Reed valve inspect | 50h |
| Carburettor / throttle body clean | 60h |
| Chain and sprockets replace | 60h |
| Shock service | 60h |
| Swingarm bearings grease | 60h |
| Steering head bearings grease | 60h |
| Wheel bearings inspect | 60h |
| Radiator, hoses and clamps | 60h |
| Bottom end inspect / rebuild | 80h |
| Water pump seal and impeller | 80h |
| Brake discs inspect | 80h |
| Wiring and connectors | 80h |
